Ethernet |
|
Switch Architecture |
Back-plane (Switching Fabric): 96 Gbps |
MAC Address |
16K MAC address Table |
Jumbo Frame |
10KB |
Connectors |
|
Network Cable |
|
LED |
|
DI / DO |
|
Environmental Limits |
|
Power Supply |
Dual DC input, 16.8 ~ 56VDC |
PoE Budget |
80W |
PoE Pin Assignment |
|
Power Consumption |
Max. 37W |
Case Dimension |
Metal case IP-30, 110 (W) x 135 (D) x 152 (H) mm |
Weight |
1.7kg |
Installation |
DIN Rail and Wall Mount* Design |
EMI & EMS |
|
Stability Testing |
|
Verifications |
EN50121-3-2 / EN50121-4 |
Safety |
EN IEC 62368-1 |
MTBF |
371,174hrs (standards: IEC 62380) |
Warranty |
5 years |
Time Synchronization |
|
Stacking |
|
Layer 3 IPv4 / 6 Routing (IPv6 ready) |
|
NAT (Network Address Translation) |
|
MACSEC |
|
Link Aggregation |
|
Broadcast / Multicast / Unicast Storm Suppression |
Storm suppression based on port bandwidth percentage & PPS |
MAC Address Table |
|
VLAN |
|
Spanning Tree |
|
Loop Protect |
|
ERPS |
|
DNS |
|
DHCP |
|
Mirroring |
|
Quality of Service |
|
Bandwidth Control (Rate Limit) |
|
ACL |
|
Discovery Protocol |
|
Multicast |
|
Security |
|
SNMP & MIB |
|
IP Stack for Managed Interface |
|
IPv6 for Managed Interface |
|
IPv6 Transition* |
|
Configuration Import and Export |
|
Firmware |
|
Monitoring |
|
Management |
|
Zero Touch |
|
Remote Management |
|
DHCP for IPv6 |
|
VPN and Tunnel |
|
WAN Protocol |
|
Dying Gasp* |
|
OAM* |
|
Unidirectional Link Detection (UDLD) |
|
Type | Version | Description | Download |
---|---|---|---|
Datasheet
|
Latest | The datasheet of DVS-8GHP-4X | Download |
Model Name | P/N | Description |
---|---|---|
DVS-8GHP-4X | DVS-8GHP-4X | -20°C ~ 60°C / -4°F ~ 140°F |
DVS-8GHP-4X | DVS-8GHP-4X-I | -40°C ~ 75°C / -40°F ~ 167°F |
